Description

Achieve incredible clarity, balance and volume with our jumbo-shaped F-40, made in Southern California. Featuring a solid Sitka spruce top and solid African mahogany back and sides, this jumbo acoustic checks all the boxes for players who prize outstanding projection and enhanced mid-range. Its predecessor, the F-48 Navarre, was only produced from 1972 to 1976 and original versions are a rare treasure. Today’s reissue manifests the same vintage charm with timeless and tasteful appointments such as a tortoiseshell pickguard, white ABS binding, and Guild’s peak logo inlaid on the headstock. Premium materials such as an East Indian rosewood bridge and fingerboard, 20:1 open-gear tuners, and a hand-cut bone nut and saddle all match today’s standards for fine acoustics. A satin varnish finish gives this guitar its familiar broken-in look and feel, while allowing the tone woods to “breathe” and reach their sonic potential. Each F-40 ships with a Guild archtop wood case with a built-in Humicase® humidification system.

• Body Shape F – Jumbo
• Top: Solid Sitka Spruce
• Back and Sides: Solid African Mahogany
• Neck: Mahogany
• Scale Length: 25 5/8″ (651mm)
• Neck Shape: C
• Nut Width: 1 11/16″ (43mm)
• Fingerboard: Indian Rosewood
• Fingerboard Radius: 12″ (305mm)
• Top Bracing Pattern: Scalloped X
• Soundhole Diameter: 4″ (102mm)
• Rosette: ABS Ring
• Top Purfling Inlay: Black and White ABS
• Body Binding: White ABS
• Neck Thickness 1st Fret: 21mm
• Neck Thickness 9th Fret: 22.5mm
• Truss Rod: Dual ActionTruss Rod Wrench: 8mm Socket Wrench
• Fingerboard Inlays: Pearloid Dots
• Frets Total: 20
• Color: Natural (NAT)
• Finish: Satin Nitrocellulose Lacquer
• Bridge: Indian Rosewood
• Bridge String Spacing: 2 1/8″ (54mm)
• Bridge Pins: Ivory Colored Plastic
• Saddle: Compensated Bone
• Hardware: Nickel Plated
• Nut: Bone
• Tuning Machines: Guild Deluxe Vintage Open Gear with Cream Oval Buttons
• Endpin: Ivory Colored Plastic
• Pickguard: Tortoiseshell
• Upper Bout Width: 12 1/2″ (318mm)
• Lower Bout Width: 17 1/4″ (438mm)
• Body Depth Upper Bout: 3 3/4″ (95mm)
• Body Depth Lower Bout: 4 3/4″ (119mm)
• Body Length: 20 1/2″ (521mm)
• Overall Length: 42.5″ (1080mm)
• Case: Guild Deluxe Humidified Wood Case
